| DRAWWORKS |
|
CLOSING UNIT |
| National 610-M 750HP with 1-1/8" Line |
|
Chiles C16011ST50 5 Station 120 Gallon |
| |
|
|
| POWER |
|
HOUSES & TANKS |
| (2) Detroit Series 60 535HP Each |
|
Top Top Doghouse 8H' x 10'W x 30'L |
| |
|
Crew Change/Parts House |
| TORQUE CONVERTORS |
|
Diesel Fuel Tank (10,000 Gal.) 2-Pumps |
| (2) National C-195-100 |
|
Water Tank (450 Bbl.) 2-Pumps |
| |
|
Ameritech Pusher House 12'W x 48'L (skidded) |
| AUXILIARY BRAKE |
|
Ameritech Crew Housing 13'W x 52'L (skidded) |
| Parmac V-80 |
|
|
| |
|
MUD SYSTEM |
| MAST |
|
2 Tank - 650 Bbl. w/ 75 Bbl. Premix |
| RS&S 141'H x 18'W 450,000 SHL on 10-1-1/8" Lines |
|
|
| 2014 CAT III Inspection |
|
SOLIDS CONTROL EQUIPMENT |
| |
|
Pumps: (4) 5" x 6" Centrifigal |
| SUBSTRUCTURE |
|
Shakers: Vortex 3000 Duel |
| DSI - 2 Box on Box 18'H x 24'W 42'L |
|
Desander: NA |
| 2014 CAT III Inspection |
|
Desilter: OWI w/ 8-4" Cones |
| |
|
Agitators: (4) 15HP Each |
| CATWALK |
|
Mud House: 10'5"W x 12' |
| 20"H x 8'W 50'L |
|
Low Pressure Hopper: Yes |
| |
|
|
| GENERATOR HOUSE |
|
IRON ROUGHNECK |
| (2) - 455KW p/b (2) Cat C-15 Engines |
|
Blohm-Voss FH 70 |
| (2) Palatek 30D Screw 30HP |
|
|
| |
|
AUXILIARY EGUIPMENT |
| MUD PUMPS |
|
Wireline Machine: Five Star |
| (2) RS F-1000 1000HP Each |
|
Deviation Recorder: Rental MD Totco 20 Degree |
| (2) 5" x 6" Charge Pumps 50HP Ea. Mounted On Pumps |
|
Recorder: Rental Pason EDR Base System |
| |
|
Pipe Spinner: OWI 35C7 Air |
| POWER |
|
Air Hoist: Ingersoll-Rand K5 |
| (2) Detroit 12V2000 900HP Each |
|
Hyd. Hoist: Braden PD12 |
| |
|
Hyd. HPU: GFP w/ (2) Pumps |
| TRANSMISSIONS |
|
Spool Skid: |
| (2) Allison 8962 Automatic |
|
|
| |
|
TUBULARS |
| POWER SWIVEL |
|
Drill Pipe: 4-1/2" 16.60# G-105 Double WB |
| Venturetech XK-250 250 Ton |
|
Drill Collars: 6-1/4" x 2-1/4" 92# |
| w/ HPU p/b CAT C-18 630HP Engine |
|
Drill Collars: 8" (Avail. Upon Request) |
| w/ Tesco Grabber Box f/ 3" Thru 8" TJ,s (Dec. 2014) |
|
Weight Pipe: 4-1/2" x 2-7/8" 42# |
| |
|
|
| TRAVELING EQUIPMENT |
|
BOP EQUIPMENT |
| Block: Brewster 250 Ton Block/Hook combo |
|
DOUBLE: HORN LWS 11" x 5000PSI |
| Hook: B.J. 6250 250 Ton Hook |
|
ANNULAR: HORN LWS 11" x 5000PSI |
| |
|
|
| ROTARY TABLE |
|
CHOKE MANIFOLD |
| CZECH C-275 27-1/2" |
|
4" x 2" 5000 PSI |
